Ford S-MAX II facelift Minivan 2.0 AT (1997 cm³, 150 hp, Diesel, Automatic)

General information

1655
1916
4804
Brand
Ford
Model
S-MAX
Vehicle class
M
Body type
Minivan
Doors
5
Seats
5, 7
Width
1,916 mm
Length
4,804 mm
Height
1,655 mm
Wheelbase
2,850 mm
Front track
1,606 mm
Rear track
1,606 mm
Trunk
1,035 l
Maximum amount of Luggage
2,200 l
Ground clearance
128 mm
Engine type
Diesel
Engine position
Front, transverse
Engine capacity
1997 cm³
Power
150 hp at 3500 rpm
Power, kW
110 kW
Torque
370 Nm
Boost
Turbocharging
Cylinder arrangement
Inline
Number of cylinders
4
Valves per cylinder
4
Fuel type
Diesel
Bore and stroke
85 × 88 mm
Compression ratio
17
CO2 Emissions, g/km
139 g/km
Emission standard
Euro 6
Front suspension
Independent, spring
Rear suspension
Independent, spring
Type of gearbox
Automatic
Number of gears
8
Drive wheel
Front wheel drive
Front brakes
Ventilated disc
Rear brakes
Disc
Maximum speed
196 km/h
Acceleration (0-100 km/h)
108 sec
Fuel consumption urban
6.10 l
Fuel consumption extra-urban
4.80 l
Fuel consumption combined
5.30 l
Weight
1,700 kg
Full mass
2,530 kg
Fuel tank
70 l
Tires size
235/55/R17, 235/50/R18, 245/45/R19
